Info tile - Open appointments
![](../../../__attachments/66458195/dates.png?inst-v=01ce9f95-f40d-424e-a7da-0f3a4bad5824)
Type
Desktop tile | |
---|---|
Entity tile |
Description
This info tile is there to display open appointments.
Configuration
Name of search | Here the exact name of the previously defined activity search is set. The default search behind shows activities of the logged-in user of the type "Date", "Meeting" and "Follow up" with status „[O] Open / not started yet“. Also the search follows user preference "Time span for activity default search in days". |
---|---|
Show activities | Activated Details to open appointments are displayed. Though "Fields" the user can define, which fields are to be displayed. Deactivated Only the number of open appointments is displayed. |
Shown fields | Here fields of the entity "Activities" are defined, which are to be displayed upon activation of option "Show activities". Technical field names are entered separated by comma (e.g. StartDate). Technical field names are displayed in the dataset by pressing the ctrl-key and mouse-over the corresponding field in the lower frame of the application at the same time. |
Example
Name of the search | C0IB_OpenActivities_Dates |
---|---|
Show activities | Activated |
Shown fields | StartDate,EndDate,DelegatedTo,DelegatedBy,Status,Subject |
